Recommended For
- 8x8mm or 10x10mm visible checker surfaces
- Decorative CFRP panels
- Thin laminate skins
- Automotive and sports appearance parts
Product / 03
Spread Tow Carbon Fiber Fabric
Spread tow carbon fiber fabric with flat tow architecture and larger visual pattern options such as 8x8 mm and 10x10 mm for lightweight panels, decorative CFRP surfaces and thin laminates.
Quick Answer
Spread Tow Carbon Fiber Fabric in one minute.
Spread tow carbon fiber fabric is a flat woven carbon fabric made from spread carbon fiber tow, giving a thin, smooth surface and large checker appearance such as 8x8mm and 10x10mm patterns for visible CFRP parts.
- Product type
- Woven Carbon Fabric
- Pattern size
- 8x8 mm / 10x10 mm; custom by review
- Tow size
- 12K / 24K; custom by specification
- Fiber grade
- T700 / custom by review
- Areal weight
- 100 / 160 / 200 / 240 / 300 / 600 g/m2; custom
- Width
- 1000 / 1270 mm; project width by review
- Documents
- TDS / SDS / COA by product scope and order agreement
- End-use review
- Some high-performance carbon fiber materials, prepregs, yarns, tow, CFRP components and related products may require end-use and end-user review before quotation or shipment.
Specification table
Spread tow fabric options
Representative spread tow fabric range. Final pattern size, tow size, weight, width and roll packing are confirmed before quotation.
| Grade | Pattern | Tow | Typical areal weight | Typical width | Typical roll length |
|---|---|---|---|---|---|
| FRPH-ST8 | 8x8 mm typical | 12K / 24K by order | 200-400 g/m² typical | 1000 / 1270 mm typical | 50 / 100 m typical |
| FRPH-ST10 | 10x10 mm typical | 12K / 24K by order | 300-600 g/m² typical | 1000 / 1270 / 1500 mm typical | 50 / 100 m typical |
| Custom spread tow | By project review | By order | By construction review | By project review | By project review |
Product overview
How Spread Tow Fabric is used.
The overview explains typical buyer context without replacing customer testing, engineering validation or official batch documents.
Spread Tow Carbon Fiber Fabric is a woven carbon reinforcement made from flattened tow, producing a wider, flatter visual pattern than conventional 3K twill or plain fabric.
It is commonly selected for lightweight panels, appearance parts, thin CFRP skins and decorative surfaces where the visual pattern and laminate thickness both matter.
Because spread tow quality depends on tow spreading, pattern size, areal weight, width and surface expectations, it is listed as its own product page while remaining part of the Woven Carbon Fiber Fabric category.
Available specifications
Common options for RFQ preparation.
Common patterns8x8 mm / 10x10 mm
CategoryWoven Carbon Fiber Fabric
ProcessWet lay-up, vacuum bagging, prepreg conversion by review
RFQ focusPattern size, weight, width, roll length and surface target
Selection and control items
| Item | Typical value | Remark |
|---|---|---|
| Pattern size | 8x8 mm / 10x10 mm common | Confirm visual target and tolerance |
| Surface quality | Uniform tow spreading and clean roll handling target | Visual inspection |
| Resin compatibility | Dry reinforcement for epoxy or prepreg conversion by review | Confirm process before quotation |
| Packing | Roll on tube, PE film, carton or pallet by order | Export label available |
Applications
Where this product is commonly specified.
Material suitability should be verified through the customer's process, design requirements and application testing.
Decorative CFRP panels
Automotive carbon surfaces
Sports equipment skins
Thin lightweight laminate panels
Marine and industrial appearance parts
Prepreg conversion projects by review
Recommended For / Not Recommended For
Match the material to the right buying situation.
This is a practical shortlist for RFQ preparation. Final suitability depends on customer testing, resin compatibility and engineering validation.
Not Recommended For
- Hidden reinforcement where appearance is irrelevant
- Pure directional strengthening
- Projects without confirmed surface appearance requirement
How to choose this product
Selection guidance before sampling.
Confirm visible pattern size: 8x8mm, 10x10mm or custom.
Confirm tow size and fiber grade.
Select areal weight according to laminate thickness and appearance requirement.
Confirm width and roll length.
Confirm surface requirement: decorative CFRP, thin laminate, panel skin or prepreg conversion.
Confirm process: wet lay-up, vacuum bagging, compression molding or prepreg conversion.
RFQ information required
Details requested for Spread Tow Carbon Fiber Fabric.
Brand availability depends on stock, batch, order quantity, destination country and compliance review. We do not imply official authorization unless separately stated.
Pattern size
Tow size
Fiber grade
Weave pattern
Areal weight
Width
Roll length
Surface appearance requirement
Application / End Use
Quantity
Destination Country
Required Documents
Documents available
Technical product documents
Document availability depends on material family, specification, order agreement and batch. Final values are confirmed by official documents, not by website examples.
Material specifications, typical properties and recommended use.
Hazard information, handling guidance and safety measures where applicable.
Batch information and material characteristics when available for confirmed orders.
Packaging and shipping
Confirm packing before shipment.
Packing method depends on roll size, component geometry, quantity and destination. Roll protection, cartons, pallets, labels and packing photos can be discussed before shipment.
FAQ
Common buyer questions.
Is spread tow carbon fabric separate from woven carbon fiber fabric?
Spread tow fabric belongs under Woven Carbon Fiber Fabric because it is woven, but it has its own product page because pattern size and tow spreading need separate RFQ details.
What pattern sizes can be requested?
8x8 mm and 10x10 mm spread tow patterns can be discussed. Other pattern sizes depend on tow, construction and order review.
Technical guide
Selecting carbon reinforcement for vacuum infusion.
Compare woven, UD, multiaxial and spread tow fabric, then prepare the laminate and process information needed for an RFQ.
Buyer guides
Technical guidance for Spread Tow Fabric.
Use these guides to compare material options and prepare a specification-first RFQ. Final order values remain subject to quotation and document review.
Carbon Fiber Fabric for Vacuum InfusionChoose woven, UD, multiaxial or spread tow carbon fiber fabric for vacuum infusion and prepare a practical reinforcement RFQ.3K vs 12K Carbon Fiber FabricCompare 3K and 12K carbon fiber fabric by appearance, areal weight, laminate build-up, handling and common applications.Spread Tow vs Traditional Carbon Fiber FabricCompare spread tow carbon fabric with traditional woven carbon fiber fabric for checker pattern, thickness, surface appearance and process selection.How to Choose Carbon Fiber Fabric by GSMChoose carbon fiber fabric by areal weight, tow size, weave, laminate thickness and application requirements.
